THICK FILM CHIP RESISTORS RCT03,05,06,12,20,25
Features
  • Extremely thin and light
  • Highly stable in auto-placement surface mounting application
  • Compatible with both flow soldering and refolw soldering
  • Available in 8mm tape and reel per EIA-RS481







Dimensions :
   unit : mm
   Dimensions
TYPE 		L W H L1 L2
FCR 03 1.60add.gif (63 bytes)0.10 0.80add.gif (63 bytes)0.10 0.45add.gif (63 bytes)0.10 0.30add.gif (63 bytes)0.20 0.30add.gif (63 bytes)0.20
FCR 05 2.00add.gif (63 bytes)0.15 1.25add.gif (63 bytes)0.15 0.50add.gif (63 bytes)0.10 0.40add.gif (63 bytes)0.20 0.35add.gif (63 bytes)0.15
FCR 06 3.10add.gif (63 bytes)0.15 1.55add.gif (63 bytes)0.15 0.55add.gif (63 bytes)0.10 0.50add.gif (63 bytes)0.25 0.50add.gif (63 bytes)0.25

¡@
Rating

    Rating
TYPE

 Power Rating
at 70¢J 		Max.
RCWV 		Max. Overload
Voltage 		Resistance
Tolerance(%) 		Resistance Rang (£[) Standard
Resistance
Values
Min. Max.
FCR03 1/10W 50V 100V add.gif (63 bytes)1%(F)
1£[		 1M£[
10M£[ 		E-96
E-24
FCR05 1/8W 150V 300V add.gif (63 bytes)1%(F)
1£[		 1M£[
10M£[ 		E-96
E-24
FCR06 1/4W 200V 300V add.gif (63 bytes)1%(F)
1£[		 1M£[
10M£[ 		E-96
E-24
