CHIP FIRM CHIP ARRAY RC A03-4D

CONSTRUCTION


Unit:mm

Dimensions
Type

L

W

H

L1

L2

P

Q

RCA03-4D
(0603)

3.2±0.2

1.6±0.15

0.5±0.1

0.30±0.15

0.35Max

0.8±0.1

0.5±0.1



Rating :

Type

Rated
Power
at70
J

Max.
Working
Voltage

Max.
Overload

Voltage

T.C.R.
(ppm/
J)

Resistance Range

Jumper
Rated
Current

Jumper
Resistance
Value

Operating
Temperature
Range

F(±1%)
E-96

G(±2%)
J(±5%)
E-24

RCA03-4D
(0603)

0.063

50V

100V

±200

100[~
470K
[

10[~
1M
[

1A

50m[
MAX

-55J~ +125J
